Home » Products » Fuel Injection Gear Pumps » Fuel Injection Gear Pump

Fuel Injection Gear Pump

Fuel Injection Gear Pump
Fuel Injection Gear Pump
Product Code : FIG 2500R 3H
Brand Name : PRAKASH
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Inlet/Outlet
  • 3/4"x 3/4'' x 3/4''
  • Flow Rate
  • 2500 LPH
  • Material
  • Solid Iron
  • Structure
  • Gear Pump
  • Pressure
  • Medium Pressure kgf/cm2
  • Seals Type
  • Mechanical Seal
Product Description

Riding on unfathomable volumes of industrial expertise, we are offering an excellent range of Fuel Injection Gear Pump. Offered pump is fabricated by our industry experts in order to meet the varied application requirements. It is made available in both anticlockwise and clockwise direction. Our skilled professionals take care that this pump meet the universally accepted guidelines of quality and is of excellent strength. Moreover, this Fuel Injection Gear Pump allow maximum speed of1500 RPM/2900* RPM.

Salient Features

  • Capacity / Range: 1000/4500 LPH at Maximum Head of 30 Kg/cm2 Pressure.
  • Positive Displacement internal Gear Pumps at Constant Pressure. For handling only non-corrosive and Non-Abrasive liquids.
  • High Precision Pumps Ensuring Desired Output.
  • Compact, easy installation in any position.
  • Trouble-free service for long period, with minimum wear.
  • Mechanical Shaft Seal, preventing leakage of liquids.
  • Noise-free and smooth running.

Design Features

  • Quality oriented manufacture.
  • Self-lubricating and self-priming; maximum vacuum  610/660 mm Hg.
  • Maximum Liquid Temperature  200oC
  • Available with Pressure Regulating Valve and external By-pass.
  • Rotation of pump-Clockwise and Anti-clockwise.
  • Wide Pressure Range.
  • Minimum Viscosity 10 Centistokes.
  • RPM 1400
Applications

Hydraulic Drive, Furnaces, Chemical Plants, Machine Tools, Fertilizers, Transformers, Petro-chemicals, Oil Burners, Diesel Engines, Boilers, Vegetable Oil Processors, LPG, Tractors, Sugar Mills, Railways, Lubricating Oils, Filter Pumping and for other industrial applications.

Technical Specification for related Series:

Model / Group

Suction Delivery

Center
By- Pass

LPH

Pump Rating
RPM

Recommend HP
at 10 Kg Pressure

FIG HC 1000 R 3H

3/4''

3/4''

1000 LPH

1400

0.75

FIG HC 1000 L 3H

3/4''

3/4''

1000 LPH

1400

0.75

FIG HC 1500 R 3H

3/4''

3/4''

1500 LPH

1400

0.75

FIG HC 1500 L 3H

3/4''

3/4''

1500 LPH

1400

0.75

FIG HC 2000 R 3H

3/4''

3/4''

2000 LPH

1400

1

FIG HC 2000 L 3H

3/4''

3/4''

2000 LPH

1400

1

FIG HC 2500 R 3H

3/4"

3/4"

2500 LPH

1400

1.5

FIG HC 2500 L 3H

3/4"

3/4"

2500 LPH

1400

1.5
